Optimized surface area pleated cartridges delivering superior flow rates and efficiency.
TRINITY FLOW-MAX Pleated filter cartridges are designed to optimize on the surface area of the media for higher flow rate, lower clean Delta P and longer Service life. High-Efficiency Pleated Filter Cartridges provide more surface area for higher flow rate and longer life. Designed for applications of food, pharmaceutical, electronic, semiconductor, and other demanding process industries. The Gradient density microfiber media provide Absolute removal ratings and high contaminant holding capacities. All components are biologically safe and meet FDA requirements.
| Media | Polypropylene, Glass Fibre |
| Inner Core | Polypropylene, Glass fibre |
| End Caps & Cage | Polypropylene |
| Gaskets & O-rings | Buna N, EPDM, Silicone, Viton, Teflon Encapsulated Viton |
| Micron Ratings | 0.2 0.3 0.45 0.6 1.0 1.2 2.0 2.5 4.0 5.0 6.0 10 20 40 50 |
| Nominal Length | 9.75, 10, 20, 30, 40 inches |
| Outside Diameter | 2.7 inches (70 mm) |
| Inside Diameter | 1.1 inches (28 mm) |
| Recommended Change-out DP | 35 PSID |
| Maximum Differential Pressure | 75 PSID (@21°C), 40 PSID (@80°C) |
| Beta Ratio | ≥1000 (99.9% efficiency) |
