Compact single-use capsule filters for sterile small volume batch filtration.
TRINITY Steri-PRO CP Series Capsule Filter is a compact filter assembly that is designed for filtration of small volume batches. It's applications are Small Volume Parenteral (SVP), Pharmaceutical / Biological Fluids, Ophthalmic solutions, filtration of developer, Fine Chemicals, Coatings and DI water.
Steri-PRO Capsules provide excellent retention of particulate matter and bio-burden reduction / sterile filtration at relatively higher flow rates and offers consistent & reproducible filter performance. Steri-PRO Capsules are constructed from all Polypropylene body and hence provide superior chemical resistance & durability in process filtration applications.
| Diameter | 2.5" |
| Length | 2.5", 4", 5", 6", 8", 10" |
| Support Material | Polypropylene |
| Filter Media | Polyethersulfone, PTFE, PVDF, Nylon |
| Shell, Cage and End Caps | Polypropylene |
| Bacteria Endotoxin | ≤ 0.25 EU/mL |
| Bacterial Retention | Samples retain a minimum of 10⁷ cfu/cm² of (B. diminuta) Brevundimonas diminuta as per modified ASTM F838, current revision |
| Maximum Differential Pressure | 60 PSI (4.2 Bar) @ 25°C |
| Maximum Operating Temperature | 80°C |
| Sterilization | 121°C for 30 minutes |
Our filtration application engineers work directly with your plant specifications to size the ideal filter media, micron rating, and vessel configurations.
