Graded-density wound depth cartridges engineered for superior dirt-holding capacity.
TRINITY Micro-STRING Wound Filters are manufactured using the latest winding technology which gives true graded density with denser layers inside and coarser layers outside. This produces superior depth filters with increased filtration capacity, longer service life and higher performance that reduce overall filtration costs. Micro-STRING filters have high structural integrity combined with a greater voids volume, giving lower pressure drop, much improved dirt holding capacity and efficiency compared to conventional wound filters.
| Media | Polypropylene / Cotton & Glass Fibre |
| Core | Polypropylene / SS 304 / SS 316 |
| End Caps | Polypropylene |
| Removal Ratings | 0.5 1 3 5 10 25 50 100 |
| O-Rings / Gaskets (SOE) | Buna N, EPDM, Silicone, Viton |
| Inside Diameter | 1 inch (25 mm) |
| Outside Diameter | 2.5 inches (63 mm) |
| Nominal Length | 9.75, 10, 20, 30, 40 inches |
| Max Operating Temp | Polypropylene – 80°C; Cotton with SS core – 120°C; Heat purified Glass – 250°C |
| Recommended Changeout | 35 PSID |
